UV Primer

Highly efficient and high yield UV Primer. Requires UV-A equipment for curing Best Option: UV-A Mercury Lamp UV-LED Recommendation: UV-A LED lamp with 365nm wave length. UV LED alternative: UV-A LED with 395nm wave length will cure the primer depending on intensity and time of exposure.


SprayMax UV Paint Repair System is comprised of four products that complement each other to complete a repair:
UV Primer part no. 3 680 019
UV Clear part no. 3 680 059
UV Blender part no. 3 680 091
UV Cleaner part no. 3 680 290

Advantages

  • High filling capacity
  • Ideal for repaired paintwork
  • Suitable as an insulation filler
  • High productivity

Article number

3680019 grey-beige

UV Primer

Application notes

Spray pass
Spray pass

Dry film thickness 1.6 -2.0 mil (40 μm - 50 μm) approx. 1 - 2 spray coats

Flash-off time
Flash-off time

End flash time before UV curing: approx. 1 min

Drying
Drying

After 4 min dried with an UV-A lamp. After 2 min dried with an UV-A LED lamp with 395nm.

Sanding 'Wet / dry'(manually)
Sanding 'Wet / dry'(manually)

Wet sanding with i.e. P 600 - P 1000 or dry sanding with i.e. P 320 - P 400
